與容量位移的外在齒輪泵從0,1 2.900 ccm或rev。
與容量位移的內部齒輪泵從1 207 ccm或rev。
與容量位移的輻形柱塞泵從1 42,9 ccm或rev。
|
大小和流速規格
|
|
|
BG8
|
2100 - 2600 CCM/U
|
|
BG7
|
1100年- 1600 CCM/U
|
|
BG6
|
550 - 900 CCM/U
|
|
BG5
|
289 - 900 CCM/U
|
|
BG4
|
110 - 517 CCM/U
|
|
BG3
|
37,4 - 120 CCM/U
|
|
BG2
|
11,8年- 43,3 CCM/U
|
|
BG1
|
0,1 - 12,7 CCM/U
|
Delivery pump units
Beinlich self-priming delivery pump units consist of external gear pumps which are made from standard materials 0.7050 (housing) / 1.8550 (shafts and gears) and FKM (static seals). They are especially suitable for the low pressure range and can convey almost every low viscosity media as well as uncritical media without fillers which are compatible to the materials used.
The engine power of the 4 pole asynchronous three-phase motor is sufficiently assessed for achieving differential pressures of up to 40 bar. Additionally, delivery pump units are available within a short delivery time, thanks to standardised units.
Performance data
- Displacements 0.1 to 72.0 cc/rev
-
Speed range 150 to 1.750 rpm
(by using a frequency converter) - Viscosity range 1 to 800 mPas
- Ambient temperature range -20 to +40°C
- Fluid temperature range / operating temperature range -20 to +150°C
- Pressure range 3 to 40 bar
-
Pre-pressure:
Max. 10 bar by using a rotary shaft seal
Max. 20 bar by using a magnetic coupling
Areas of application
- Filling plants
- Printing machines
- Paint industry
- Filter technology
- Generator construction
- Cooling machine
- Mechanical engineering
- Hydraulics
- Oil processing
- Tank facility construction
- Compressors
- Vacuum plants
- Machine tools
More information on delivery pump units can be found in our ，For detailed information and technical specifications, please contact our
High pressure pumps
The TR / TRG radial piston pump was designed for the high pressure range up to 700 bar and for uncritical, clear media. The pump is available in different versions. Moreover, Beinlich offers the product series TRD/TRGD with coated pistons for poorly and non-lubricating media. Additionally, various seals can be assembled to meet the different requirements (triple shaft seal with block chamber, mechanical seal with block chamber or magnetic coupling).
Performance data
- Displacements 0.42 to 42.88 cc/rev
- Speed range 300 to 2,000 rpm
- Viscosity range 0.4 to 2,000 mPas
- Ambient temperature range -30 to +60°C
- Fluid temperature range / operating temperature range -20 to +150°C
- Pressure range 200 to 700 bar
Areas of application
- Test stands
- High pressure hydraulics
- High pressure dosage
More information on high pressure pumps can be found in our For detailed information and technical specifications, please contact our
System solutions
Together with our affiliated companies VSE Volumentechnik, DST Dauermagnet-SystemTechnik and HBE Hydraulik-Komponenten, we are developing system solutions from one single source in direct contact with our customer. The delivery range extends from “pump free shaft” to a complete unit with
- High precision flow measurement
- Advanced evaluation electronics
- Permanent magnetic couplings
- Conversion kits
- Bellhousings
- Foot flanges
- Damping elements
The special requirement profiles for individual and system solutions result from the close corporation between manufacturer and user. Technical consultation and guidance tailored to our clients' needs and a thorough understanding of the application requirements round off our worldwide customer service.
Examples for individually developed system solutions:
- Metering pumps for polyols with abrasive fillers and separate bypass valves
- Metering pump with block chamber for the polyurethane industry as a complete unit with gear box motor, bellhousing and coupling
- Complete unit in bronze version for foam agent pump with integrated flow meter and safety valve
More information on delivery pumps can be found in our . We depending on your customised requirements.
