意大利Coel Motori Srl剎車電機
簡要說明：*功率：0.09KW～7.5KW鋁合金壓鑄外殼
*轉數:3000/1500/1000/750rpm 等
*安裝方式:B5標準法蘭, B14小法蘭, B3臥式
*ICE認證：寬電壓：（220/380V，240/415V，260/440V，280/480V）寬頻率：50/60HZ
*電機軸承:瑞典SKF或日本NSK，低噪音、振動小
*F級絕緣，耐155℃高溫*防護等級IP55
詳細介紹：
剎車馬達（DC）
1、剎車馬達，提供當電源切斷后，可手動釋放剎車，轉動馬達出力。
2、剎車來今片是由高摩擦系數和長壽命的材料制成，
剎車次數可達1，00，000次后調整一次，可耐較高的溫
升、當溫度在75℃時仍能全負載使用。
3、剎車馬達使用AC電源，經由整流器轉換后供應給DC剎
車線圈使用其特性是噪音低、沖擊小。正反轉均能有效地達到剎車動作。
4、剎車部分零部件充足，不影響售后服務問題
5、可以帶釋放裝置
產品型號：F71A2 A71B2 F71C2 F80A2 F80B2 F90SA2 F90SB2 F90LA2 F100LA2 F112MB2 F132SA2 F132SB2 F132MB2 F160MA2 F160MB2 F160LA2 F180LA2 F200LA2 F200LB2
F71A4 F71B4 F71C4 F80A4 F80B4 F80C4 F90SA4 F90LA4 F90LB4 F90LC4 F100LA4 F100LB4 F100LC4 F112MB4 F132SB4 F132MA4 F132MB4 F160MB4 F160LA4 F160LB4 F180LA4 F180LB4 F200LB4
F71A6 F71B6 F71C6 F80A6 F80B6 F90SA6 F90LA6 F100LA6 F100LB6 F112MB6 F132SB6 F132MA6 F132MB6 F160MB6 F160LA6 F160LB6 F200LA6 F200LB6
F71B8 F80A8 F80B8 F90SA8 F90LA8 F100LA8 F112MB8 F132SB8 F132MB8 F160MA8 F160MB8 F160LA8 F180LB8 F200LA8
FD71A2/4 FD80A2/4 FD90LA2/4 FD100LB2/4 FD132SB2/4
FDA71B2/6 FDA80B2/6 FDA90SA2/6 FDA100LB2/6 FDA132SB2/6
FDA71B2 FDA80B2 FDA90LB2 FDA100LA2
F Motors Type
-
Products
-
COEL - BRAKE MOTORS
-
F Motors Type
F type motors are closed and externally ventilated. The brake groups and all the motor parts are designed and made by Coel.
The brake group is supplied on series with AC 3phase electromagnet but DC version is also available on request.
The F series motors can be driven by inverter but in this case the brake supply must be separated from the one of the motor.
The motor frames of motors are in die cast pressed aluminium from 71 to 160 frame and in cast iron for frames 180 and 200.
The shafts of frames 71 to 132 are fitted with an hexagon on the back side for the manual rotation of the shaft. The brake can be manually released with a special screw supplied with the motor. The friction tracks are in cast iron and auto ventilated.
The F series motors are designed for very heavy duty cycles, quick braking action, constant braking time.
STRONG, RELIABLE AND SUITABLE FOR ANY APPLICATION SINCE 1976
FK Brake Motors
-
Products
-
COEL - BRAKE MOTORS
-
FK Brake Motors
FK motors are closed and externally ventilated.
The brake is supplied DC with rectifier.
FK motors can be driven by inverter but in this case it's necessary tu supply the brake separately from the motor.
The cases are in die pressed aluminium and braking surfaces are in cast iron.
Shaftes are fitted with an hexagon on the back side for the manual rotation of the shaft.
The lateral hand release of the brake is available on request.
Available from size 56 to size 160 IEC.
FK motors are compact and light available with a wide range of options.
DC brake motors also available with double brake for stage application or with flywheel for gradual start and braking.
FM Brake Motors
-
Products
-
COEL - BRAKE MOTORS
-
FM Brake Motors
FM series brake motors are externally ventilated and completely closed.
FM motors are available from frame 225 up to 315; all the components of the motor parts are in cast iron and the motors are supplied painted blue RAL5010.
The brakes mounted are DC and made to ensure a very long life.
The very strong structure of FM series brake motors ensures high reliability for high power applications.
The brake courrent supply is separated from the motor supply as standard.
